12 Guage 1-5/8" X 6-1/2" 10' Back-to-Back Channel, ST316

Thumbnail Filmstrip of 12 Guage 1-5/8" X 6-1/2" 10' Back-to-Back Channel, ST316 Images

    Purchase 12 Guage 1-5/8" X 6-1/2" 10' Back-to-Back Channel, ST316

    12 Guage 1-5/8" X 6-1/2" 10' Back-to-Back Channel, ST316

    Part Number: W151S610
    Discontinued Part Number(s):
    Florida Strut: FS12314NSBBS610
    Versabar: VA11201S610
    Wesanco/ZSI: W151ST31610
  • Description

    W151S610, 12 guage channel back-to-back strut, 10 feet long, with 316 Stainless Steel finish.

    • Strut: 1 5/8" (41mm) width x 6 1/2" (165mm) height
    • Back-to-Back 10' in length
    Technical Specifications

    Additional technical specifications, including 'Allowable Beam Loads', 'Allowable Column Loads', and 'Section Properties' can be found on the W151 Channel Combination 12 Gauge 1-5/8" x 6-1/2" category page.

    Finish Finish Code Description
    Stainless Steel: Channel ST316 A 240 TYPE 316 Heat resisting chromium and chromium-nickel stainless steel plate, sheet, strip for pressure vessel.
    Features
    • Channels are manufactured by the cold roll forming process which produces cross sections of uniform dimensions within tolerances established by the Metal Framing Manufacturer's Association, Metal Framing Standards Publication No. MFMA-4.
    • Steel used in the manufacture of channels conforms to the ASTM specifications under the Specifications tab below.
    • Design is based on AISI S100-2016 "Specification for the Design of Cold-Formed Steel Structural Members." Maximum bending stress used in design is 25,000 pounds per square inch (PSI). This is based upon a virgin steel minimum yield stress of 33,000 psi cold worked to an average yield stress of 42,000 psi.
    • Welds meet the performance requirements of section 4 of AISI S100-2016 "Specification for the design of Cold-Formed Steel Structural Members." All multiple sections of two or more single channels are resistance spot-welded approximately 2" to 3" (51mm to 76mm) on center.
    W151S610
